BridgeMaster E – Type Approved Radars

• Fully type approved for standard and high speed craft
• Wide choice of radar configuration
• Unique, hands-off clutter and gain optimization option
• Simple, straightforward operation
• Choice of control configuration
• Fast, easy installation and commissioning
• 40 target tracking on ARPA/ATA models
• Multi-layer radar maps
• Full IBS interfacing to DNV Watch-1
• 2-way and 6-way interswitching

______________________________________________________________________________________________________

• Flat-screen high-resolution TFT display
• Complete ARPA functionality
• Interswitching
• ClearVision automatic clutter suppression
• Improved small target detection
• VDR and AIS interfaces
• Tracks up to 100 radar and AIS targets
• Multi-layer user-created radar maps and voyage plans
• Multi-purpose display window for user selectable information
• iUSB storage device port
• Basic Control Panel with ergonomic trackball control
• Online Operator’s Manual including innovative iHelp functions

______________________________________________________________________________________________________

• Improved detection capability by new MIC and I/F amplifier
• High resolution LCD display providing crisp echo images
• Two independent X- and S-band radars can be interswitched to meet SOLAS requirements on ships 3,000 – 10,000 GT
• Easy operation by customizable function keys, trackball/wheel palm module, and rotary controls
• Low spurious magnetrons meeting ITU-R unwanted emission standards
• Standard ARPA functions displaying 100 ARPA targets acquisition
• Display up to 1000 AIS symbols
• Optional track ball system for user friendly operation from a remote station
• ARPA function is provided as a standard
• Interswitch capability without dedicated hardware for dual or multiple radar/ARPA installation – up to four radar systems can be connected in the network

______________________________________________________________________________________________________

• Output capacity 12 kW (FR-2115), 25 kW (FR-2125) or 50 kW (FR-2155)
• Daylight-bright resterscan 21-inch multi-color, high-resolution display
• New technologies of signal treatment
• New cast aluminum scanner gearbox and new series of streamlined antennas
• Easy operation by a combination of discrete keys, Track ball and menu
• Reliable CPA and TCPA warning in any plotting mode, accurate target data
• Optional 42 rpm scanner for high speed vessels
• Electronic Plotting Aid (EPA) fitted as standard, Automatic Radar Plotting Aid (ARPA) option exceeding IMO and IEC standards
• Voltage is 115/230 V AC

______________________________________________________________________________________________________

• Improved detection capability by new MIC and I/F amplifier
• High resolution LCD display providing crisp echo images
• Two independent X- and S-band radars can be interswitched to meet SOLAS requirements on ships 3,000 – 10,000 GT
• Easy operation by customizable function keys, trackball/wheel palm module, and rotary controls
• Low spurious magnetrons meeting ITU-R unwanted emission standards
• Standard ARPA functions displaying 100 ARPA targets acquisition
• Display up to 1000 AIS symbols
• Optional track ball system for user friendly operation from a remote station
• ARPA function is provided as a standard
• Interswitch capability without dedicated hardware for dual or multiple radar/ARPA installation – up to four radar systems can be connected in the network

______________________________________________________________________________________________________

• -High Resolution 28 Inch (360mm effective) Color CRT Display
• 25 kW, X-Band Transceiver Aloft
• 14 Range Scales from 1/8th to 120 NM (non IMO), 96 NM (IMO)
• 5 Transmitter Pulse Lengths and 4 Repetition Rates
• Auto Tuning, 6 dB Low Noise Receiver with Auto Sea & Rain Clutter Reduction
• 16 Level Target Display in Yellow, Green or Tri-color Mode
• Day or Night, Dark Blue, Light Blue or Black Background Color Scheme
• Head-Up, North-Up, TB/North-Up, Course-Up or TM/North-Up Display Modes
• 3 Pre-set Function (Macro) Keys for Optimal System Performance
• Dual Visual and Audible Alert Radar Guard Zone Alarms
• 2 Switched EVRM’s and EBL’s, One Pair May be Off-Centered
• 10 Target, 10 Symbol Manual Acquisition, Manual Track (EPA) Electronic Plotter
• GC8-A2 Gyro Converter Supplied as Standard Equipment

______________________________________________________________________________________________________

JRC’s new JMA-5300Mk2 integrates the latest leading technologies with a set of new features that allows running radar images faster and more efficiently than ever before. The new JMA-5300Mk2 series integrates a wide dynamic range receiver that, compared to conventional models, significantly improves the differentiation of noise and targets under sea clutter. The radar system overcomes different sources of unwanted signals, maintaining a constant level of overall visible clutter.

• 19” high visibility LCD screen
• Constaview™ digital signal processing
• TEF™ multi-level target enhancement
• High speed version available
• Brushless antenna motors for extended lifetime
• Complies with SOLAS carriage requirements for vessels under 10.000

______________________________________________________________________________________________________

JRC JMA-9900 series ARPA/Radar is developed to enhance the radar performance, user-friendly operation and visibility, which meet the performance standards of radar, ARPA and AIS information indication, which are specified in IMO. The JMA- 9900 main functions include; sea and rain/snow clutter suppression, sensitivity adjustment, interference reflector, bearing and range measurement using a trackball, fixed/variable range markers and electronic bearing line, ARPA, and AIS information function. In addition, this has the functions of color display setting, own track display, NAV line and mark display, True Motion presentation, radar performance monitoring and built-in switchover function (Inter-switch) up to 2 radars.

______________________________________________________________________________________________________

JRC’s new JMA-9100 ARPA radar series integrates the latest leading technologies and represents a significant step change in terms of reliable performance and cost-effectiveness, making it one of the most advanced radar products available today.

• 23″ high visibility LCD screen
• ConstaviewT digital signal processing
• TEFT multi-level target enhancement
• High speed version available
• Wide dynamic range receiver
• Complies with SOLAS carriage requirements for vessels above 10.000 GT.
